FUSED ALUMINA ZIRCONIA (AZ)
Suntek Fused Alumina Zirconia enjoys extremely wear-resistant and anti-friable characters. It is mainly used to make resin bonded, foundry-type grinding wheels, heavy duty Coated abrasives, and for pressure blasting.
SUNTEK AZ25
Characteristics:
Mineral structure | a- Al2O3, m. t – ZrO2 |
Absolute density | 4.35 g/cm3 |
Knoop hardness | 1780 kg/mm2 |
Melting point | 1950℃ |
Chemical Analysis:
Al2O3 | ZrO2 | SiO2 | Fe2O3 | Na2O | TiO2 |
75% | 24% | 0.20% | 0.20% | 0.08% | 0.15% |
 |  |
| AZF25 | AZS25 |
Product Data Sheet :
Suntek Fused Alumina Zirconia AZ 25
SUNTEK AZ40
Characteristics:
Mineral structure | a- Al2O3, m. t – ZrO2 |
Absolute density | 4.65 g/cm3 |
Knoop hardness | 1620 kg/mm2 |
Melting point | 1880 ℃ |
Color | Grey |
Chemical Analysis:
Al2O3 | ZrO2 | SiO2 | Fe2O3 | Na2O |
59% | 40% | 0.10% | 0.20% | 0.08%c |
AZ40 Microstructure:
 |  |
Product Data Sheet:
Suntek Fused Alumina Zirconia AZ 40
