FUSED ZIRCONIA
Suntek Material supplies a full series of Fused Zirconia products, product includes Fused Monoclinic Zirconia, Fused Calcium Stabilized Zirconia, Fused Magnesia Stabilized Zirconia and Fused Yttria Stabilized Zirconia.
Applications of Fused Zirconia Powders:
Zirconium silicate based ceramic pigments, used in tiles, glazes, sanitary ware
Refractory ceramics, molten metal filters
Glass and gemstones composition
Electronic ceramics: PZT, multi-layer ceramic capacitor (MLCC), Dielectric components
Thermal spray powders (TSP), EBPVD ingots for thermal barrier coatings (TBC)
Structural ceramics for the industry: valve components, wear & abrasion resistant components, milling medias,bearings, cutting tools, …
Ferrules and sleeves for optical fiber connectors
Consumer and decorative ceramics: watches, knives, mobile phone part,…
Dental ceramics
Ionic conductive ceramics: gaz sensors, solid oxide fuel celles (SOFC)
Fused Monoclinic Zirconia Powder:
Code | Chemical Composition(%) | Size D50 (μm) | ||||
ZrO2+HfO2 | SiO2 | Al2O3 | Fe2O3 | TiO2 | ||
ZF-M-12 | ≥99 | ≤0.30 | ≤0.10 | ≤0.04 | ≤0.13 | Hollow Balls or in customized powder |
Main applications:
Ceramic pigment, welding rod, brake additive, Zirconia nozzle, sliding plate,etc.
Fused Calcium Stabilized Zirconia:
Code | Chemical Composition ( % ) | Stabilized rate ( % ) | True densiy (g/cm3 ) | Size | |||||
ZrO2+HfO2 | Al2O3 | SiO2 | CaO | Fe2O3 | TiO2 | ||||
ZF-C-94 | ≥94 | ≤0.60 | ≤0.60 | 3.5-4.2 | <0.15 | <0.30 | > 95 | >5.6 | Hollow ball, Dense grain or powder according to customer’s requirement |
Main applications:
Fused Magnesia Stabilized Zirconia:
Code | Chemical Composition ( % ) | Stabilized rate ( % ) | True density (g/cm3 ) | Size | ||||||
ZrO2 | Al2O3 | SiO2 | MgO | Y2O3 | Fe2O3 | TiO2 | ||||
ZF-M-A | ≥ 95 | ≤0.1 | ≤0.2 | 2.5-3.5 | ≤0.3 | ≤0.10 | ≤0.1 | 70-85 | >5.7 | customized |
ZF-M-B | ≥ 94 | ≤0.4 | ≤0.4 | 2.5-3.5 | ≤0.5 | ≤ 0.15 | ≤0.2 | 50-70 | >5.6 | customized |
Main applications:
Fused Yttria Stabilized Zirconia:
Code | Chemical Composition(%) | Stabalisation Rate | True Density | Size | ||||||
ZrO2 | Al2O3 | SiO2 | CaO | Y2O3 | Fe2O3 | TiO2 | ||||
ZF-Y-5-B | >93 | <0.3 | <0.4 | <0.2 | 4.8-5.5 | <0.1 | <0.2 | >50 | >5.8 | Hollow bubble, Dense grain or powder according to customer’s requirement
|
ZF-Y-7-a | ≥90 | ≤0.1 | ≤0.2 | ≤0.2 | 7-8.5 | ≤0.1 | ≤0.1 | 75-85 | >6.1 | |
ZF-Y-7-b | ≥91 | ≤0.1 | ≤0.1 | ≤0.1 | 7-8.5 | ≤0.1 | ≤0.1 | >98 | >6.1 | |
ZF-Y-7-c | ≥90 | ≤0.3 | ≤0.4 | ≤0.2 | 7-8.5 | ≤0.1 | ≤0.2 | 75-85 | >6.0 | |
ZF-Y-7-d | ≥90 | ≤0.1 | ≤0.2 | <0.5 | 7-8.5 | ≤0.1 | ≤0.1 | >95 | >6.0 | |
ZF-Y-9 | >89 | <0.2 | <0.4 | <0.2 | 8.8-9.8 | <0.1 | <0.2 | >85 | >6.1 | |
ZF-Y-13-A | >84 | <0.1 | <0.1 | <0.1 | 13-14 | <0.05 | <0.05 | >95 | >6.2 | |
ZF-Y-13-B | >84 | <0.2 | <0.2 | <0.2 | 13-14 | <0.1 | <0.2 | >95 | >6.2 |
Main applications:
